BLUSTREAM Contractor 4x4 HDBaseT Matrix Kit - 1080p to 70m

Logga in för priser
BS-C44KIT

BLUSTREAM Contractor 4x4 HDBaseT Matrix Kit - 1080p to 70m

Contractor 4x4 HDBaseT™ Matrix Kit - 70m (4K up to 40m), Bi-directional IR, PoC, Simultaneous HDMI / HDBaseT™ on Output 1, RS-232 & TCP/IP Control, HDCP 2.2 Compliant, Web GUI, Includes 4 x HEX70B-RX HDBaseT™ Receivers

Description
Our Contractor 4x4 HDBaseT™ Matrix offers unprecedented performance and value for the custom installation market.

The C44-KIT is a 4K HDCP 2.2 matrix package, delivering HDMI, Bi-directional IR and PoC up to lengths of 70m over a single CAT cable.
The matrix also provides advanced features including simultaneous HDBaseT™ / HDMI on output 1 and a web browser interface module for control and configuration of the matrix.

The C44-KIT is supplied with 4 x HEX70B-RX receivers.

Key Features
• Advanced HDBaseT™ technology offering uncompressed video and audio with zero latency
• Features 4 x HDMI inputs which can be independently routed to 4 x HDBaseT™ outputs
• Output 1 features simultaneous HDMI and HDBaseT™ output
• Extends HDMI up to a distance of 70m over single CAT cable
• Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports 3D signal display
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
• Web interface module for control and configuration of matrix
• Supports bi-directional IR on all HDBaseT outputs
• Supplied with Blustream IR receivers and emitters
• Control via front panel, IR, RS-232 and TCP/IP
• Supports PoC (Power over Cable) to supplied HDBaseT™ receivers
• 3rd Party drivers available for all major home control brands
• 1U Design for 19" rack mount integration - mounting kit included
• Advanced EDID management
• HDCP 2.2 compliant
• Supplied with 4 x HEX70B-RX receivers

Specifications
• Video Input Connectors: 4 x HDMI Type A, 19-pin, female
• Video Output Connectors: 1 x HDMI Type A, 19-pin, female, 4 x HDBaseT™ RJ45 connector
• RS-232 serial port: 1 x DB-9, female
• TCP/IP Control: 1 x RJ45, female
• IR Input ports: 5 x 3.5mm stereo jack
• IR Output ports: 4 x 3.5mm mono jack
• Rack-Mountable: 1 U rack height, rack ears included
• Case Dimensions (without feet) (W x D x H): 440mm x 202mm x 44mm
• Dimensions (W x D x H): 440mm x 212mm x 52mm
• Shipping Weight: 2.7kg
• Operating Temperature: 32°F to 104°F (0°C to 40°C)
• Storage Temperature : -4°F to 140°F (-20°C to 60°C)
• Power Supply: 1 x 24V/3.5A DC

Box Contents
• 1 x C44
• 4 x HEX70B-RX
• 1 x Rack Mounting Kit
• 4 x Mounting Kit for HEX70B-RX
• 1 x 24V/3.5A Power Supply
• 1 x IR Remote Control
• 4 x IR Emitters
• 5 x IR Receivers
• 1 x Quick Reference Guide
