Soundtube 4 x 700W Dante enabled DSP Amp
MCA7004t
Dante-Enabled Networking Amplifier
The SoundTube Entertainment MCA7004t multichannel amplifier is Dante enabled, and allows for fixed resistance and fixed voltage output modes. At 4 ohms, this amplifier offers 700W respectively per channel. The 4.3” LCD touchscreen on the front panel allows for easy access to gain controls, input matrixing, as well as output mode selection. The included software, STNet MCA Control, provides the user with complete control over the amplifier. This software enables the user to monitor the real-time status of the amplifier, and set up various DSP functions in real time. These DSP features include functions such as compressor, limiter, noise gate, parametric equalization, matrix router, delay, and more!
Specifications
Color: Black
UPC: 644216231508
Manufacturer: SoundTube
Manufacturer's Category: STNet IP-Addressable and Dante Series
Depth: 16.63
Height: 3.47"
Width/Diameter: 19"
Shipping Weight: 28 lbs / 12.7 kg
Carton Height: 7.0 in / 177.8 mm
Carton Length: 21.0 in / 533.4 mm
Carton Width: 21.0 in / 533.4 mm
Input Type: Euroblock balanced / unbalanced, DANTE, AES3 digital audio
Output Power:
- Stereo/Matrix@16Ωx4: 250W×4
- Stereo/Matrix@8Ω×4: 500W×4
- Stereo/Matrix@4Ω×4: 700W×4
- Bridged @16Ω×2: 700W×2
- Bridged @8Ω×2: 1400W×2
- Fixed Voltage 70V@9.8Ω: 500Wx4
- Bridge Fixed Voltage 100V@10Ω: 1000W×2
Input Sensitivity: 2 dBu, 6 dBu, 12 dBu
Input Resistance: 20kΩ balanced
Frequency Response (@1W power): 20Hz-20KHz ±1dB
THD+ N (@1/8 power): ≤0.05%
SNR (A-weighted): ≥96dB
Damping Coefficient (@ 1KHz): ≥200@ 8 ohms
Isolation (@ 1KHz): ≥95dB
Indicator Light: Power, Protection, Distortion
Cooling Method: Fan Cooling
Max Power Consumption (all channels driven, pink noise input): 1020W
1/8 Power Consumption (all channels driven, pink noise input): 720W
Power Requirements:
~110V 50Hz, ~110V 60Hz
~120V 50Hz, ~120V 60Hz
~220V 50Hz, ~220V 60Hz
~230V 50Hz, ~230V 60Hz
~240V 50Hz, ~240V 60Hz
MCA7004t
Dante-Enabled Networking Amplifier
The SoundTube Entertainment MCA7004t multichannel amplifier is Dante enabled, and allows for fixed resistance and fixed voltage output modes. At 4 ohms, this amplifier offers 700W respectively per channel. The 4.3” LCD touchscreen on the front panel allows for easy access to gain controls, input matrixing, as well as output mode selection. The included software, STNet MCA Control, provides the user with complete control over the amplifier. This software enables the user to monitor the real-time status of the amplifier, and set up various DSP functions in real time. These DSP features include functions such as compressor, limiter, noise gate, parametric equalization, matrix router, delay, and more!
Specifications
Color: Black
UPC: 644216231508
Manufacturer: SoundTube
Manufacturer's Category: STNet IP-Addressable and Dante Series
Depth: 16.63
Height: 3.47"
Width/Diameter: 19"
Shipping Weight: 28 lbs / 12.7 kg
Carton Height: 7.0 in / 177.8 mm
Carton Length: 21.0 in / 533.4 mm
Carton Width: 21.0 in / 533.4 mm
Input Type: Euroblock balanced / unbalanced, DANTE, AES3 digital audio
Output Power:
- Stereo/Matrix@16Ωx4: 250W×4
- Stereo/Matrix@8Ω×4: 500W×4
- Stereo/Matrix@4Ω×4: 700W×4
- Bridged @16Ω×2: 700W×2
- Bridged @8Ω×2: 1400W×2
- Fixed Voltage 70V@9.8Ω: 500Wx4
- Bridge Fixed Voltage 100V@10Ω: 1000W×2
Input Sensitivity: 2 dBu, 6 dBu, 12 dBu
Input Resistance: 20kΩ balanced
Frequency Response (@1W power): 20Hz-20KHz ±1dB
THD+ N (@1/8 power): ≤0.05%
SNR (A-weighted): ≥96dB
Damping Coefficient (@ 1KHz): ≥200@ 8 ohms
Isolation (@ 1KHz): ≥95dB
Indicator Light: Power, Protection, Distortion
Cooling Method: Fan Cooling
Max Power Consumption (all channels driven, pink noise input): 1020W
1/8 Power Consumption (all channels driven, pink noise input): 720W
Power Requirements:
~110V 50Hz, ~110V 60Hz
~120V 50Hz, ~120V 60Hz
~220V 50Hz, ~220V 60Hz
~230V 50Hz, ~230V 60Hz
~240V 50Hz, ~240V 60Hz
