RTI 5-in Intelligent Surface Touchpanel - White - Available in June
The new IST-5 touchpanel elevates system control in all commercial and residential settings. It starts with a hi- resolution 5” capacitive-touch screen with a 854x480 resolution with true-black display filter for exceptional clarity. With an ultra-thin bezel, near-flush mount (just 0.4”/ 11mm off the wall), and elegantly compact form-factor, the IST-5 makes an elegant statement in landscape or portrait mount. Built-in 10/100/1000 Base-T Ethernet with PoE enables seamless two-way system control, video, and remote programming.
The hi-res display is perfect for the 100% customizable RTI user interface, with fast response and easy swiping. The proximity sensor enables a fast hands-free wake while the ambient light sensors automatically adjust display brightness. The IST-5 plays hi-resolution video in H.264 or H.265 format and is ideal for viewing security camera feeds. Dual speakers, far-field microphone array, SIP- readiness, plus full duplex capability make the IST-5 perfect for intercom and as an interface with video doorbells. The 2-mic array features a mute button plus hardware-based echo cancellation.
With its included mounting brackets, the IST-5 mounts easily in a US single gang box.
Fits Swedish Electrical Back Box.
Key Features
• Hi-resolution 5” capacitive-touch screen (854x480) with ultra-thin bezel.
• Near-flush mount (less than 0.4”/11mm off wall).
• Ethernet and Wi-Fi options for control and communication.
• PoE or 12V DC power options.
• Exceptional video streaming and two-way intercom at H.264 or H.265 format.
• Dual speakers and far-field microphone array (with mute button).
• Proximity and ambient light sensors.
• Portrait or landscape with auto-rotate.
Specifications
• Power (Power Supply not included): +12V DC, 2A, or PoE (802.3af)
• Power Management: Adjustable backlight/proximity sensor
• Touchscreen Display: High-brightness 24-bit color IPS LCD, FWVGA (854x480 pixels) with true black display filter, Integrated high-resolution capacitive-touch screen
• Display Size: 5” (127 mm) diagonal, 16:10 aspect ratio
• Display Backlight: LED Backlit, 400nit
• Ethernet Port: RJ45, 10/100/1000 Base-T, with Power-over-Ethernet
• Microphone: Built-in digital microphone array with mute button, hardware-based echo cancellation
• Speakers: Two (2), 8Ω, 1 Watt, 100-20KHz
• Communications: Ethernet / Network IP, WiFi 2.4G/5G 802.11a/b/g/n/ac
• System Memory: 4GB RAM, 64GB ROM
• Device Capability: Total number of devices is limited only by memory
• Macro Capability: Total number of macros is limited only by memory
• Operating Temperature: +32°F to +122°F (0°Cto +50°C)
• Operating Humidity: 5% to 95% Non-condensing
• Mounting: Wall-Mount
• Installation: US standard single gang
• Outer Bezel Dimension (W x H x D): 44.61” x 3.33” x 0.41”, 133 mm x 84.6 mm x 10.5mm
• Wall Cut-Out Dimension (W x H): 2.75” x 4.5” 70mm x 114.5mm
• Depth in Wall (Wall Box): 1.75” (44.5mm)
• Weight: 7.05 oz (200g)
• Warranty: Three Years (Parts & Labor)
Included in the Box
IST-5, metal wall bracket (1), mounting bracket screws (4), single gang low voltage mounting bracket (1)
The new IST-5 touchpanel elevates system control in all commercial and residential settings. It starts with a hi- resolution 5” capacitive-touch screen with a 854x480 resolution with true-black display filter for exceptional clarity. With an ultra-thin bezel, near-flush mount (just 0.4”/ 11mm off the wall), and elegantly compact form-factor, the IST-5 makes an elegant statement in landscape or portrait mount. Built-in 10/100/1000 Base-T Ethernet with PoE enables seamless two-way system control, video, and remote programming.
The hi-res display is perfect for the 100% customizable RTI user interface, with fast response and easy swiping. The proximity sensor enables a fast hands-free wake while the ambient light sensors automatically adjust display brightness. The IST-5 plays hi-resolution video in H.264 or H.265 format and is ideal for viewing security camera feeds. Dual speakers, far-field microphone array, SIP- readiness, plus full duplex capability make the IST-5 perfect for intercom and as an interface with video doorbells. The 2-mic array features a mute button plus hardware-based echo cancellation.
With its included mounting brackets, the IST-5 mounts easily in a US single gang box.
Fits Swedish Electrical Back Box.
Key Features
• Hi-resolution 5” capacitive-touch screen (854x480) with ultra-thin bezel.
• Near-flush mount (less than 0.4”/11mm off wall).
• Ethernet and Wi-Fi options for control and communication.
• PoE or 12V DC power options.
• Exceptional video streaming and two-way intercom at H.264 or H.265 format.
• Dual speakers and far-field microphone array (with mute button).
• Proximity and ambient light sensors.
• Portrait or landscape with auto-rotate.
Specifications
• Power (Power Supply not included): +12V DC, 2A, or PoE (802.3af)
• Power Management: Adjustable backlight/proximity sensor
• Touchscreen Display: High-brightness 24-bit color IPS LCD, FWVGA (854x480 pixels) with true black display filter, Integrated high-resolution capacitive-touch screen
• Display Size: 5” (127 mm) diagonal, 16:10 aspect ratio
• Display Backlight: LED Backlit, 400nit
• Ethernet Port: RJ45, 10/100/1000 Base-T, with Power-over-Ethernet
• Microphone: Built-in digital microphone array with mute button, hardware-based echo cancellation
• Speakers: Two (2), 8Ω, 1 Watt, 100-20KHz
• Communications: Ethernet / Network IP, WiFi 2.4G/5G 802.11a/b/g/n/ac
• System Memory: 4GB RAM, 64GB ROM
• Device Capability: Total number of devices is limited only by memory
• Macro Capability: Total number of macros is limited only by memory
• Operating Temperature: +32°F to +122°F (0°Cto +50°C)
• Operating Humidity: 5% to 95% Non-condensing
• Mounting: Wall-Mount
• Installation: US standard single gang
• Outer Bezel Dimension (W x H x D): 44.61” x 3.33” x 0.41”, 133 mm x 84.6 mm x 10.5mm
• Wall Cut-Out Dimension (W x H): 2.75” x 4.5” 70mm x 114.5mm
• Depth in Wall (Wall Box): 1.75” (44.5mm)
• Weight: 7.05 oz (200g)
• Warranty: Three Years (Parts & Labor)
Included in the Box
IST-5, metal wall bracket (1), mounting bracket screws (4), single gang low voltage mounting bracket (1)
